Description
Cisco Catalyst C9200L-24PXG-2Y-A | 24-Port Multigigabit PoE+ Switch, Network Advantage
Overview
The cisco c9200l-24pxg-2y-a is a high-performance, multigigabit PoE+ enterprise access switch purpose-built for high-density Wi-Fi 6/6E wireless deployments, power-heavy IoT ecosystems, and converged wired-wireless networks. Featuring 8 specialized multigigabit line ports (supporting up to 10G speeds) alongside 16 standard Gigabit PoE+ interfaces, this versatile hardware asset functions perfectly as an agile cisco 10gbe switch engine at the campus edge. Out-of-the-box, it delivers up to 370W of inline power (expandable to 740W), cleanly fueling high-draw wireless access points, HD IP tracking cameras, and corporate VoIP stations.
Equipped with 2 native 1/10/25G SFP28 high-speed uplinks, the c9200l-24pxg-2y-a eliminates backhaul bottlenecks to core or distribution layers across corporate office buildings, medical centers, and sprawling retail chains. Built on Cisco's specialized UADP 2.0 Mini ASIC pipeline and running the modular Cisco IOS XE operating system under a full Network Advantage license, this model opens up comprehensive Layer 3 dynamic routing, micro-segmentation, and advanced Software-Defined Access (SD-Access) topology configurations.
-
Related Reading & Architecture Resource Guides:
-
Choosing between a 24-port or 48-port mGig footprint for your wireless upgrade? Read our specialized matrix: Cisco C9200L-48PXG-2Y vs 24PXG-2Y for WiFi 6E Deployments.
-
Evaluating fixed C9200L formats against modular C9200 chassis? Check out our comparison guide: Cisco Catalyst 9200 vs 9200L Switches Features & Differences.
-
Staging a complete access layer overhaul? Review our migration blueprint: How to Replace Legacy Cisco Switches for Modern Enterprise Networks.
-
📥 Download Technical Specifications: Designing a next-generation high-bandwidth wireless network layout? Enter your business work email below to download the official datasheet PDF to verify exact forwarding rates, latency metrics, and transceiver compatibility limits for the c9200-24pxg series family.
Highlights
-
Multigigabit Access for Wi-Fi 6/6E: Includes 8 dedicated mGig ports supporting 100M/1G/2.5G/5G/10G adaptive line rates, completely removing wireless access layer bottlenecks during dense corporate access point rollouts. To help pick your endpoints effectively, read our Smart Way to Pick Cisco Wi-Fi 6E Access Points Guide.
-
High-Speed 25G Uplinks (Backward Compatible): Features 2 integrated SFP28 uplink sockets natively supporting 1G, 10G, and line-rate 25G aggregations straight to your campus distribution or core switches without needing add-on modules.
-
Flexible PoE+ Power for Edge Devices: Offers a stable default 370W PoE budget (via 1 x PWR-C5-600WAC), dynamically scalable to 740W max power delivery with dual PSUs to seamlessly energize high-tier IoT environments. For precise power budget maps, read our Cisco AP Deployment & PoE Budget Guide.
-
StackWise-80 High Availability: Cluster up to 8 fixed switches into a single logical network node utilizing a combined 80 Gbps of stacking backplane bandwidth with sub-50ms stateful failovers.
-
Programmable UADP 2.0 Mini ASIC: Features a future-ready programmable pipeline layout ensuring hardware-accelerated QoS optimization, non-blocking wire-speed forwarding, and native software-defined capabilities.
-
Network Advantage Feature Set: Unlocks full enterprise Layer 3 dynamic routing protocols right out of the box, including EIGRP, IS-IS, OSPF, HSRP, along with macro-segmentation tools like VRF, VXLAN, LISP, and Cisco TrustSec SGT.
-
Advanced Zero-Trust Security: Protects your localized enterprise edge borders via line-rate MACsec link encryption, Secure Boot protocols, hardware-anchored Trust Anchor Module (TAM), and automated 802.1X port-level identity authentication.
-
Unified Automation & Visibility: Cloud-ready infrastructure supporting central orchestration via Cisco Catalyst Center (formerly DNA Center) and Meraki Dashboard cloud monitoring, backed by streaming telemetry data loops for real-time visibility.
Use Cases & Deployment Scenarios
-
Wi-Fi 6 / Wi-Fi 6E Campus Access Layers: The ideal anchoring cisco 10gbe switch deployment platform to eliminate multi-gigabit access point aggregation bottlenecks across modern universities, medical facilities, and smart corporate office layouts.
-
Distributed Retail Chains & Smart Stores: Centralized IT deployment structures to cleanly distribute data and continuous PoE+ power across point-of-sale (POS) systems, surveillance matrices, and specialized smart storefront sensors.
-
Enterprise Branch & SMB Network Layers: Provides a high-performance access option for expanding mid-market businesses requiring advanced micro-segmentation, isolated tenant VLANs, and long-term hardware scaling.
-
High-Density Offices & Collaboration Spaces: Delivers stable, deterministic packet throughput for latency-sensitive applications like corporate VoIP setups, multi-party video conferencing links, and cloud database access inside hybrid work environments.
-
Surveillance & Smart Building IoT Deployments: Reliable centralized power injection and unified policy control for high-definition IP camera networks, environmental controls, and digital signage assets.
Recommended Accessories
To configure your multigigabit c9200l-24pxg-2y-a layout effectively, pair your fixed switch configuration with original Cisco components and verified transceiver options.
| Model | Description | Use Case |
|---|---|---|
| PWR-C5-600WAC | 600W AC PSU (default) | Standard PoE deployment |
| PWR-C5-600WAC (Secondary) | Redundant PSU | Increase PoE to 740W |
| C9200L-STACK-KIT | Stack kit | Enable StackWise-80 |
| STACK-T4-1M | Stacking cable | Switch stacking |
| SFP-10G-SR | 10G SFP+ | Short-distance uplink |
| SFP-25G-SR-S | 25G SFP28 | High-speed aggregation |
Comparison with Similar Models
| Model | Downlinks | Uplinks | PoE Budget | License | Best For |
|---|---|---|---|---|---|
| C9200L-24PXG-2Y-A | 8 mGig + 161G | 225G | 370W / 740W | Advantage | Wi-Fi 6 / Enterprise |
| C9200L-24PXG-2Y-E | Same | Same | Same | Essentials | SMB / basic routing |
| C9200L-48PXG-2Y-A | 8 mGig + 401G | 225G | 740W / 1440W | Advantage | Large campus |
Specifications
| Parameter | Specification | Value |
|---|---|---|
| Ports | 8 mGig + 16 1G PoE+ | High-density access |
| mGig Speeds | 100M / 1G / 2.5G / 5G / 10G | Wi-Fi 6/6E ready |
| Uplinks | 2 1/10/25G SFP28 | Core aggregation |
| PoE Budget | 370W / 740W | Device power |
| Switching Capacity | 292 Gbps | Non-blocking |
| Forwarding Rate | 229.16 Mpps | Wire-speed |
| Stacking | 80 Gbps | Scalability |
| MAC Table | 16,000 | Network scale |
| IPv4 Routes | 11,000 | Branch routing |
| IPv6 Routes | 1,500 | Future-ready |
| DRAM / Flash | 2 GB / 4 GB | System |
| Jumbo Frame | 9198 bytes | Large data |
| Power Supply | PWR-C5-600WAC | Default |
| Weight | 12.0 lb (5.44 kg) | Rack deployment |
| MTBF | 374,730 hours | Reliability |
Why Choose the C9200L-24PXG-2Y-A?
-
Built for Modern Wireless Networks
True multigig + 25G uplinks = no bottlenecks for Wi-Fi 6/6E -
Full Network Advantage Capability
Unlocks advanced routing (EIGRP, IS-IS) and segmentation (VXLAN, VRF) -
High ROI for Channel Partners
A high-demand, fast-moving SKU ideal for local inventory and rapid deployment -
Enterprise Reliability
Backed by Cisco Enhanced Limited Lifetime Warranty (E-LLW) -
Scalable for Future Growth
From SMB to enterprise - ready for SD-Access and automation
