Dell Dual Socket (P+) FCLGA4189 3rd Gen CPU DDR4 iDRAC9 Motherboard – 00FMRT / 0FMRT
The Dell 0FMRT (00FMRT) Dual-Socket Motherboard ( Systemboard ) is a high-performance system board designed for enterprise workloads and data center standardization. Built for Dell 15th Generation PowerEdge servers, this motherboard supports 3rd Generation Intel Xeon Scalable processors (Ice Lake architecture) and advanced DDR4 memory configurations.
Engineered for scalability, security, and performance, it integrates iDRAC9 remote management and PCIe Gen 4 expansion capabilities for modern infrastructure demands.
Compatible Servers
-
Dell PowerEdge R650 (1U Rackmount)
-
Dell PowerEdge R750 (2U Rackmount)
Key Specifications
| Component | Specification |
|---|---|
| System Compatibility | Dell PowerEdge R650, R750 (15th Generation) |
| Processor Support | Up to two 3rd Gen Intel Xeon Scalable (Ice Lake) CPUs |
| CPU Socket | FCLGA4189 |
| Max Cores per CPU | Up to 40 cores |
| Memory Slots | 32 DDR4 DIMM slots (16 per CPU) |
| Memory Type | Registered ECC (RDIMM) & Load-Reduced (LRDIMM) |
| Memory Speed | Up to 3200 MT/s |
| Max Memory Capacity | Up to 2TB (RDIMM) or 8TB (LRDIMM) |
| PCIe Expansion | Up to 8 × PCIe Gen 4 slots |
| Networking (LOM) | Broadcom 5720 Dual-Port 1Gb Ethernet |
| Management | Integrated iDRAC9 |
| Storage Interfaces | SAS, SATA, U.2 NVMe, BOSS (M.2 Boot) |
| Front Ports | 1 × VGA, 1 × USB 2.0, 1 × micro-USB (iDRAC Direct) |
| Rear Ports | 1 × USB 2.0, 1 × USB 3.0, 2 × RJ-45 Ethernet |
Key Features
GPU Support
Supports up to:
-
Two double-width 300W GPUs
-
Four single-width 150W accelerators
Enterprise Security
-
Silicon Root of Trust
-
System Lockdown
-
Cyber-resilient architecture
Advanced Cooling Options
-
Standard air cooling
-
Optional processor liquid cooling
Form Factor Deployment
Designed for use in:
-
1U chassis (PowerEdge R650)
-
2U chassis (PowerEdge R750)
This motherboard is intended for Dell PowerEdge 15th Generation platforms only. Please verify server model and configuration compatibility before purchase.
